TECO SG2 - Page 162

Chapter 12 Technical Specification 135
Versus true
value
±2%±0.12V
Conversion
time
Sensor
impedance
<1K ohm
12-4-3 24 DC type 20 I/O
Item
SG2-20HR-D& SG2-20KR-D
SG2-20HT-D& SG2-20KT-D
Standard Discrete
Input
High Speed Input Analog input as
discrete input
Analog input
Input
circuit
I3~I8
I1,I2 I9,IA,IB,IC
Quantity 6 2 4 4
Current 3.1mA/24V DC 3.1mA/24V DC 0.63mA/24V <0.17 mA/10V
ON State >1.875mA/15V >1.875mA/15V >0.163mA/9.8V
OFF State < 0.625mA/5V < 0.625mA/5V < 0.083mA/5V
Maximal
Cable
Length
100 m 100 m 100 m 30m (shielded)
On=>Off On=>Off On=>Off
5ms 0.5ms Typical: 5ms
Off=>On Off=>On Off=>On
Response
time
3ms 0.3ms Typical: 3ms
Type 0~10 V DC
Display
Resolution
0.01V DC
Conversion 10
Versus true
value
±2%±0.12V
