Chapter 3: Menu reference > Option 14 Program Users
36 Challenger10 Administrators Manual
Total users
You may need to know how many users are stored in the Challenger panel’s
memory (including the default user 50). For example, if the total number of users
is 21, then 20 users have been added, plus the master user 50.
From the Program Users menu, press [4] [ENTER].
Total Users 21
Press ENTER
Press [ENTER] to return to the User screen.
Card learn
A card reader RAS can be used to enter a user’s card data (card bits) into the
Challenger system by presenting (badging) the card at the reader during the user
creation process.
From the Program Users menu, press [5] [ENTER] to select a RAS to be the card
learn reader (RAS 1 is selected by default).
1
Card RAS:
Enter the card reader’s RAS address in the range 1 to 16 and 65 to 80, and then
press [ENTER].
16
Card RAS:
Press [ENTER] to return to the User screen.
Programming non-Tecom magnetic card formats
The following procedure must be used to allow non-Tecom format cards such as
credit cards, financial institution cards, and so on, to be programmed as users.
Your system must be equipped with the appropriate card reader in order to
perform this function.
Use the following steps to record the non-Tecom format card enrolment number
in the user record.
1. Swipe the card in the reader.
2. If the card is not recognized by the system, an event will be logged in
history as “Card/Pin” followed by an enrolment number of up to 10 digits
(for example, “Card/Pin 1234512345”). Note the enrolment number, which
will be recorded as the PIN code when programming the user.
