PL-680 9
METHOD 3: ATS (AUTO TUNING STORAGE)
FM ATS:
1. Fully extend the telescopic antenna
and press the [FM] button to select
FM band.
2. To automatically store all available
stations, press & hold the [FM] button;
"PRESET" will flash in the top right
corner of the display while the frequency
starts running. The frequency stops running once the ATS
operation has completed. Rotate the
all stored FM stations.
MW/LW ATS:
1. Press the [AM] button to select MW/LW band.
2. Press & hold the [AM] button to perform ATS on the MW or LW
band.
[TUNING] knob to browse
MHz
SL EEP
PAGE PRESET
Ni-MH
Battery
FM
0 1 2 3 4 5
flashing
SW ATS:
Fully extend the telescopic antenna and press the SW [ ] or [ ]
button to select SW band. There are two modes for SW ATS tuning:
Mode A: Press & hold the [ ] button to ATS the stations within all
meter bands
Mode B: Press & hold the [ ] button to ATS the stations within
present meter band only.
Notes:
1. While performing ATS in FM, MW/LW or SW (mode A) bands,
previously stored stations are replaced by the newly found
stations.
2. While performing ATS in SW (mode B) band, previously stored
stations are not replaced. Instead, all newly found stations are
stored in blank memory positions.
3. If the surrounding area has too much interference or many
mirror/blank stations are stored during ATS, try to contract the
telescopic antenna (for FM and SW) or rotate the radio (for MW
and LW). Also try to push the [ANT. GAIN] switch into "NORMAL"
or "LOCAL" position. Then perform ATS again.
WORKING WITH STATION MEMORIES
