TECSYSTEM NT935 WS EVO - Programming Notes

14
NT935 WS EVO
20
The display shows ON (CH4),
the FAN 2 LED flashes
Default 45°C
21
Set the desired threshold FAN2 ON
If FAN 2 NO is selected skip to
step 24
22
The display shows OFF (CH4)
the FAN2 LED flashes
Default 35°C
23
Set the desired threshold FAN2 OFF
24
HFN (NO) is displayed
The FAN1-FAN2 LEDs flash
Fan cyclic test
for 5 min. every “n” hours
25
Set the desired number of hours
Default NO = function
disabled
26
FCD (NO) is displayed
Fault for quick temperature
increase (°C/sec)
27
Set the desired value
(FCD info on page 19)
Default NO
(function excluded)
28
VOT (NO) is displayed
(VOTING info on page 16)
29
Select YES or NO
Default NO
(function excluded)
30
FLS (ALARM) is displayed
Blinking ALARM LED
(info FAIL SAFE on page 18)
31
Select YES or NO
Default NO
32
FLS (TRIP) is displayed
Blinking TRIP LED
33
Select YES or NO
Default NO
34
FLS (FAULT) is displayed
Blinking FAULT LED
35
Select YES or NO
Default YES
36
END is displayed
End of programming
37
Press ENT to save the set data
and exit programming
incorrect programming of the
LED values indicated (note 6)
38
Return to step 1
PROGRAMMING NOTES
1) The MODE key allows reversing the programming steps according to the sequence 28-26-8-1
2) The TEST key allows exiting programming without saving the modified data.
3) After 1 minute's keyboard inactivity programming is abandoned without saving the data.
4) During programming the control unit does not control/protect the monitored machine.
5) At the end of programming the control unit is restarted and the FAULT relay is disabled until the unit is fully restarted.
6) If pressing ENT, “Err” appears, it means that one of the following mistakes has been made:
ERR ALL. = ALARM ≥ TRIP
ERR FAN = FAN-OFF ≥ FAN-ON. (FAN1 OR FAN2)
ERR INT = INT FAN-OFF ≥ FAN-ON (FAN1) DELTA <10°C
The device automatically prepares itself for the programming step of the error committed
NOTE: EVERY TIME THE CONTROL UNIT PROGRAMMING, WITH CONFIRMATION OF DATA SAVING, THE
VALUES STORED IN T-MAX ARE RESET AT THE TIME OF STORING.
