34/40 366430 / 04.2013_b
ANNEXE
1
Gamme Silensys® | Silensys® range | Baureihe Silensys® | Gama Silensys® |
Gamma Silensys® | модельный ряд Silensys® | Seria Silensys®
* Vitesse max. - Max speed - Max. Drehgeschwindigkeit - Velocidad máx. - Velocità massima - Скорость макс
366430 / 04 2013 b
29/40
Gamme Silensys®
|
Silensys® range
|
Baureihe Silensys®
|
Gama Silensys®
|
Gamma Silensys®
| модельный ряд Silensys
Taille
Size
Größe
Tamaño
Dimensione
Размер
ANNEXE
1
[m
3
/h] [in]
[mm] [in]
[mm] [Kg] [Kg] HBP [bar]
LBP [bar]
Modèles
Models
Modelle
Modelos
Modelli
модель
Applications
Application
Anwendung
Aplicación
Applicazione
оборудован
ие
Fluide
frigorigène
Refrigerant
Kältemittel
Fluido
frigorígeno
Fluido
frigorigeno
Хладагент
M R-404A CBP SILVS9514Z 2 700 3/4 19,05 3/8 9,5 85 107 29,7 - 25,7 2,7 - 4,2
M R-404A CBP SILVS9517Z 2 700 7/8 22,2 1/2 12,7 86 108 29,7 - 25,7 2,7 - 4,2
M R-404A CBP SILVS9521Z 2 700 7/8 22,2 1/2 12,7 86 108 29,7 - 25,7 2,7 - 4,2
L R-404A CBP SILVS9524Z 5 400 7/8 22,2 5/8 15,9 127 142 29,7 - 25,7 2,7 - 4,2
L R-404A CBP SILVS9528Z 5 400 7/8 22,2 5/8 15,9 143 158 29,7 - 25,7 2,7 - 4,2
L R-404A CBP SILVS9536Z 5 400 7/8 22,2 5/8 15,9 146 161 29,7 - 25,7 2,7 - 4,2
L R-404A CBP SILVS9544Z 5 400 7/8 22,2 5/8 15,9 150 165 29,7 - 25,7 2,7 - 4,2
XL R-404A CBP SILVSD9548Z 6 600 1 1/8 28,6 5/8 15,9 250 269 29,7 - 25,7 2,7 - 4,2
XL R-404A CBP SILVSD9556Z 6 600 1 1/8 28,6 5/8 15,9 270 289 29,7 - 25,7 2,7 - 4,2
XL R-404A CBP SILVSD9572Z 6 600 1 3/8 34,9 7/8 22,2 279 297 29,7 - 25,7 2,7 - 4,2
XL R-404A CBP SILVSD9588Z 6 600 1 3/8 34,9 7/8 22,2 286 305 29,7 - 25,7 2,7 - 4,2
S R-134a HBP SILAE4440Y 1 650 3/8 9,5 1/4 6,35 66 86 17 - 13 0,6 - 1,4
S R-134a HBP SILAE4450Y 1650 3/8 9,5 1/4 6,35 66 86 17 - 13 0,6 - 1,4
S R-134a HBP SILAJ4461Y 1 650 1/2 12,7 1/4 6,35 66 86 17 - 13 0,6 - 1,4
S R-134a HBP SILAJ4476Y 1 650 1/2 12,7 3/8 9,5 68 88 17 - 13 0,6 - 1,4
S R-134a HBP SILAJ4492Y 1 650 1/2 12,7 3/8 9,5 68 88 17 - 13 0,6 - 1,4
S R-134a HBP SILAJ4511Y 1 650 5/8 15,9 3/8 9,5 69 89 17 - 13 0,6 - 1,4
S R-134a HBP SILRG4445Y 1 650 3/8 9,5 1/4 6,35 58 78 17 - 13 0,6 - 1,4
S R-134a HBP SILRG4550Y 1 650 3/8 9,5 1/4 6,35 58 78 17 - 13 0,6 - 1,4
S R-134a HBP SILRG4460Y 1 650 1/2 12,7 1/4 6,35 59 79 17 - 13 0,6 - 1,4
S R-134a HBP SILRG4476Y 1 650 1/2 12,7 3/8 9,5 59 79 17 - 13 0,6 - 1,4
M R-134a HBP SILFH4518Y 2 700 5/8 15,9 3/8 9,5 79 101 17 - 13 0,6 - 1,4
M R-134a HBP SILFH4525Y 2 700 5/8 15,9 3/8 9,5 81 103 17 - 13 0,6 - 1,4
L R-134a HBP SILAG4528Y 5 400 7/8 22,2 3/8 9,5 128 143 17 - 13 0,6 - 1,4
L R-134a HBP SILAG4534Y 5 400 7/8 22,2 3/8 9,5 128 143 44 0,6 - 1,4
L R-134a HBP SILAG4537Y 5 400 7/8 22,2 3/8 9,5 128 143 17 - 13 0,6 - 1,4
L R-134a HBP SILAG4543Y 5 400 7/8 22,2 3/8 9,5 128 143 17 - 13 0,6 - 1,4
XL R-134a HBP SILAGD4556Y 6 600 1 1/8 28,6 5/8 15,9 241 260 17 - 13 0,6 - 1,4
XL R-134a HBP SILAGD4568Y 6 600 1 1/8 28,6 5/8 15,9 241 260 17 - 13 0,6 - 1,4
XL R-134a HBP SILAGD4574Y 6 600 1 1/8 28,6 5/8 15,9 253 272 17 - 13 0,6 - 1,4
XL R-134a HBP SILAGD4586Y 6 600 1 1/8 28,6 5/8 15,9 253 272 17 - 13 0,6 - 1,4
Débit d’air*
Air flow*
Luftvolu-
menstrom*
Caudal
de aire*
Debito
d’aria*
Расход*
Ø Aspiration
Ø Suction
Ø Saugseite
Ø Aspiración
Ø Aspirazione
Ø всасывание
Ø Départ liquide
Ø Liquid exit
Ø Druckseite
Ø Salida de líquido
Ø Partenza liquido
Ø жидкостная линия
Poids
Weight
Gewicht
Peso
Peso
Вес.
poids
emballé
(carton +
palette)
packed
weight
(carton +
pallet)
Pressostat
(coupure-enclenchement)
Pressure switch
(Cut (for the pressure switch)
(Engage)
Pressostat
(Ausschalten - Einschalten)
Pesostato
(Corte - Conexión)
Pressostato
(Interruzzione - Avviamento)
Отключение
(для реле давления -
Включение)
* Vitesse max. - Max speed - Max. Drehgeschwindigkeit - Velocidad máx. - Velocità massima - Скорость макс


Größe



























-




























Masa



























[m
3
/h]
[in] [mm] [in] [mm] [Kg] [Kg] HBP [bar] LBP [bar]
