Teknatool NOVA DVR XP - Control Operations at Stop Mode; Starting Operation

115-0214-004 28
5.0 CONTROL OPERATIONS AT STOP MODE
5.1 Starting operation
Insert the drive power plug into the 220-230/115v, 50/60 Hz socket. There must be the sound signal and
display messages step-by-step will be: (shown on the next page)
TEKNATOOL Int. v4.54xs03 2006
TEKNATOOL PROMO-
TES SAFETY FIRST
ALWAYS WEAR
FACE SHIELD
ENSURE CORRECT
SPEED SELECTED
Beeper will sound twice. Wait for end it or press key
0
OFF
to cancel. After that the display message will
be:
TEKNATOOL Int.
v4.54xs03 2006
The version number means:
v4.54
- control software version
x
- XC164CS Infineon microcontroller with flash memory
s
- Serial interface
03
- Interface software version
Note: This guide is updated for the v4.54x control software versions and s03 interface software version,
which are compatible with each other. The control software versions v4.41x and higher will also
work but without some functions.
The drive will make the preparation procedure, check the fault conditions and after that the LCD will
show the Main display page (for Stop operation):
LCD View
Comments
Set 500rpm=#2D
S
Reference speed and number (D = default speed number)
Ready to run >>
R
<</>> - reference direction (forward/reverse)
Note: S = parameter can be modified using Set Function.
R, P, E, M = parameter(s) can be modified by one of keys in accordance with the keyboard
description legend (see above).
The drive is in Stop mode and ready to run the motor forward with the speed of 500 rpm.
