Appendix A: Specifications
370B User Manual
A-11
Table A-6: NonĆstore Horizontal Deflection System
Characteristic Performance Requirement Operating Information
Cursor WINDOW Cursor
Accuracy (typical) within 0.06 division
Collector Volts
Range 50 mV/div to 500 V/div in a 1 -2-5 sequence.
x10 MAG extends maximum sensitivity to 5
mV/div (50 mV resolution).
Accuracy (typical) Within2%ofWINDOW cursor readout + 0.1
x HORIZ/DIV setting.
Maximum displayed noise Less than 0.02 % of MAX PEAK VOLTS
setting.
Base/Emitter Volts
Range 50 mV/div to 5 V/div in a 1-2-5 sequence.
x 10 MAG extends maximum sensitivity to 5
mV/div (50 mV resolution).
Accuracy (typical) Within2%ofWINDOR cursor readout + 0.1
x HORIZ/DIV setting.
Input impedance At least 100 MW
Maximum displayed noise Less than 10 mV
p-p
With 1 MW resistor connected between Base
and Emitter terminals, BASE OPEN
configuration, and 0 Number of Steps.
Step Generator Display
Range 1 step/div
1 step/10 div With x10 MAG
10 steps/div With STEP MULTI .1 x
Accuracy Within 0.3 division
Display Offset
Range
"10 divisions in 0.1 division resolution.
Accuracy Within 1.5 % of offset + 0.1 x HORIZ/DIV
setting.
Display x10 MAG
Accuracy Within 1.5 % of window cursor readout + 0.3
x HORIZ/DIV setting.
Display Invert
Accuracy Within 0.1 x HORIZ/DIV setting.
