Appendix A: Specifications
A-12 370B User Manual
Table A-7: Digital Storage Horizontal Acquisition
Characteristic Performance Requirement Operating Information
A/D Converter
Resolution 10 bits for 10.24 divisions. 100 counts per
division.
Max data points 1024
Max sampling rate Line frequency x 1024
Min sampling rate Line frequency x 2
Collector Volts
Range 50 mV/div to 500 V/div in a 1-2-5 sequence.
X10 MAG extends maximum sensitivity to 5
mV/div (50 mV resolution).
Accuracy Within 1.5 % of dot cursor readout + 0.05 x
HORIZ/DIV setting.
Base/Emitter Volts
Range 50 mV/div to 2 V/div in a 1-2-5 sequences.
x 10 MAG extends maximum sensitivity to 5
mV/div (50 mV resolution)
Accuracy Within 1.5 % of dot cursor readout + 0.05 x
HORIZ/DIV setting.
Step Generator display
Range 1 step/div
1 step/10 div
10 steps/div
With X10 MAG
With STEP MULTI .1 x
Accuracy (typical) Within 0.3 division
Display offset
Range
"10 divisions in 0.1 division resolution.
Accuracy Within 1.5 % of DOT cursor readout + 0.01 x
HORIZ/DIV setting.
Display x10 MAG
Accuracy Within 1.5 % of DOT cursor readout + 0.3 x
HORIZ/DIV setting.
Display Invert
Accuracy Within 0.04 % x HORIZ/DIV setting.
