Reference
370B User Manual
3-25
Figure 3-18: Averaging display.
1. Obtain a blank 3.5-inch floppy disk (2HD type). If the floppy disk is write
protected, move the write protect tab to the write-enable position (see Figure
3–19).
2. Insert the disk with the label side up (see Figure 3–20), pushing it in firmly
until it clicks into place.
3. Press the Setup SAVE button while holding down the FAST/SHIFT button,
then press the SAVE button. The floppy disk has now been formatted.
Formatting a disk destroys all information currently on the disk.
Format only new disks or disks whose contents you do not want to keep.
4. Set the Memory Index number to 2, then press the Setup RECALL button.
Observe that the I
C
–V
CE
characteristic curves are displayed.
5. Change the Memory Index number to 17.
Floppy Disk Drive
