Removal and Installation Procedures
3. Use a wire cutte
r to remove the two cable ties. (See Figure 4-23 on page 4-45.)
4. Remove the two screws, tie mount clips, and cable posts. (See Figure 4-24 on
page 4-45.)
5. Disconnect the ribbon cables at J1050, J2000, and J5000 from the AWG12G
board.
6. Disconnect these cables:
The cable at J115A from the AWG12G board to the CH1 OUT10G board
(J150).
The cable at J116A from the AWG12G board to the CH1 OUT10G board
(J170).
The cable at J115B from the AWG12G board to the CH2 OUT10G board
(J150).
The cable at J116B from the AWG12G board to the CH2 OUT10G board
(J170).
The cable at J1430 from the AWG12G board to the Trigger Input
connector.
The cable at J1440 from the AWG12G board to the Event Input connector.
The cables from J100, J110, J600, and J700 on the CH1 OUT10G board.
The cables from J100, J110, J600, and J700 on the CH2 OUT10G board.
7. Use a wire cutter to remove the cable tie securing the Dynamic Jump In
cable and disconnect it from J1600. The Dynamic Jump In is only available
on the AWG7000C Series.
8. Remove the 11 screws securing the AWG12G board to the chassis.
9. Lift the board away from the chassis.
AWG7000B and AWG7000C Series Service Manual 4–47
