Troubleshooting
Table 4-6: Diagnostics error codes (cont.)
Error code Error log message
Possible defect
on board Note
1410P0002
Analog Level Diag CH1 positive (negative) 5db
attenuator failed. expected 0.56234, actual xxxxx
OUT10G OUT10G: K610, K710
1410P0003
Analog Level Diag CH1 positive (negative) 10db
attenuator failed. expected 0.31627, actual xxxxx
OUT10G OUT10G: K620, K720
1410P0004
Analog Level Diag CH1 positive (negative) 20db
attenuator failed. expected 0.100000, actual xxxxx
OUT10G OUT10G: K630, K730
1410P0005
Analog Level Diag CH1 positive (negative) 50mhz filter
failed. expected 0.992, actual xxxxx
OUT10G OUT10G: K660, K760
1410P0006
Analog Level Diag CH1 positive (negative) 200mhz filter
failed. expected 0.998, actual xxxxx
OUT10G OUT10G: K670, K770
1410P0007
Analog Level Diag CH1 positive (negative) amplitude
cal failed. expected 2.07, actual xxxxx
OUT10G OUT10G: U800
1410P0008
Analog Level Diag CH1 positive (negative) hfd dac
reference failed.
AWG12G AWG12G: U100A, U150A
1410P0009
Analog Level Diag CH1 positive (negative) output offset
failed. expected 0.50V(0.0V), actual xxxxx
OUT10G OUT10G: U900, U910, U920
141000010
Analog Level Diag CH1 internal offset 8bit failed.
expected 0.0mV, actual xxxxxmV
AWG12G AWG12G: U100A, U150A
141000011
Analog Level Diag CH1 internal offset 10bit failed.
expected 0.0mV, actual xxxxxmV
AWG12G AWG12G: U100A, U150A
141000012
Analog Level Diag CH1 can’t find 8bit outamp offset
cross point. expected 0.0mV, actual pos: xxxxxmV,
neg: xxxxxmV
AWG12G AWG12G: U100A, U150A
141000013
Analog Level Diag CH1 can’t find 10bit outamp offset
cross point. expected 0.0mV, actual pos: xxxxxmV,
neg: xxxxxmV
AWG12G AWG12G: U100A, U150A
141000015
Analog Level Diag CH1 5db attenuator gain balance
failed.
OUT10G OUT10G: K610, K710
141000016
Analog Level Diag CH1 5db attenuator gain balance
failed.
OUT10G OUT10G: K610, K710
141000017
Analog Level Diag CH1 10db attenuator gain balance
failed.
OUT10G OUT10G: K620, K720
141000018
Analog Level Diag CH1 20db attenuator gain balance
failed.
OUT10G OUT10G: K630, K730
141000019
Analog Level Diag CH1 filter 50mhz gain balance failed. OUT10G OUT10G: K660, K760
141000020
Analog Level Diag CH1 filter 200mhz gain balance
failed.
OUT10G OUT10G: K670, K770
141000021
Analog Level Diag CH1 amp gain balance failed. OUT10G OUT10G: U800
1420M0001
Marker Level Diag CH1 M ARKER M offset failed. OUT10G
U120, U170, U230, U240, U330,
U340
AWG7000B and AWG7000C Series Service Manual 4–61
