Tektronix AWG7082C User Manual

Troubleshooting
Table 4-6: Diagnostics error codes (cont.)
Error code Error log message
Possible defect
on board Note
1420M0002
Marker Level Diag CH1 MARKER M positive offset
failed.
OUT10G
U120, U170, U230, U240, U330,
U340
1420M0003
Marker Level Diag CH1 MARKER M negative offset
failed.
OUT10G
U120, U170, U230, U240, U330,
U340
1420M0004
Marker Level Diag CH1 MARKER M amplitude failed. OUT10G
U120, U170, U230, U240, U330,
U340
1420M0005
Marker Level Diag CH1 MARKER M amplitude
correction failed.
OUT10G
U120, U170, U230, U240, U330,
U340
150000000
The error occurred in the EEPROM read. 1st=FST
2nd=SND FST: the data that is received from EEPROM
at the first read check SND: the data that is received
from EEPROM at the second read check, which is
implemented after writing 0x55 to EEPROM
OUT10G OUT10G-CH2: U 500, U550
150000001 Message varies depending on the situation.
OUT10G OUT10G-CH1: U 500, U550
1510P0001
Analog Level Diag CH2 positive (negative) 5db
attenuator failed. expected 0.56234, actual xxxxx
OUT10G OUT10G: K610, K710
1510P0002
Analog Level Diag CH2 positive (negative) 5db
attenuator failed. expected 0.56234, actual xxxxx
OUT10G OUT10G: K610, K710
1510P0003
Analog Level Diag CH2 positive (negative) 10db
attenuator failed. expected 0.31627, actual xxxxx
OUT10G OUT10G: K620, K720
1510P0004
Analog Level Diag CH2 positive (negative) 20db
attenuator failed. expected 0.100000, actual xxxxx
OUT10G OUT10G: K630, K730
1510P0005
Analog Level Diag CH2 positive (negative) 50mhz filter
failed. expected 0.992, actual xxxxx
OUT10G OUT10G: K660, K760
1510P0006
Analog Level Diag CH2 positive (negative) 200mhz filter
failed. expected 0.998, actual xxxxx
OUT10G OUT10G: K670, K770
1510P0007
Analog Level Diag CH2 positive (negative) amplitude
cal failed. expected 2.07, actual xxxxx
OUT10G OUT10G: U800
1510P0008
Analog Level Diag CH2 positive (negative) hfd dac
reference failed.
AWG10G AWG10G: U100B, U150B
1510P0009
Analog Level Diag CH2 positive (negative) output offset
failed. expected 0.50V(0.0V), actual xxxxx
OUT10G OUT10G: U900, U910, U920
151000010
Analog Level Diag CH2 internal offset 8bit failed.
expected 0.0mV, actual xxxxxmV
AWG12G AWG12G: U100B, U150B
151000011
Analog Level Diag CH2 internal offset 10bit failed.
expected 0.0mV, actual xxxxxmV
AWG12G AWG12G: U100B, U150B
151000012
Analog Level Diag CH2 can’t find 8bit outamp offset
cross point. expected 0.0mV, actual pos: xxxxxmV,
neg: xxxxxmV
AWG12G AWG12G: U100B, U150B
151000013
Analog Level Diag CH2 can’t find 10bit outamp offset
cross point. expected 0.0mV, actual pos: xxxxxmV,
neg: xxxxxmV
AWG12G AWG12G: U100B, U150B
4–62 AWG7000B and AWG7000C Series Service Manual
