Input-output port specifications
Fast Edge output step amplitude
and offset
1200 mV differential into a 100 Ω load with a -300 mV common mode.
Fast Edge output step frequency 1 kHz ± 20%
Auxiliary output logic levels
V
out
high V
out
low (true)
≥2.5 V into 1 MΩ load,
≥1.0 V into 50 Ω load to ground
≤0.7 V into 1 MΩ load
≤0.25 V into 50 Ω load to ground
B, C, D 12.5 GHz Clock Out
(UltraSync)
1.3 V
p-p
(6 dBm)
Timebase reference output
frequency
10 MHz and 12.5 GHz outputs
Internal reference output voltage
(typical)
10 MHz Vout pk-pk > 800 mV peak-peak into 50 Ω
> 1.6 V peak-peak into 1 MΩ (internally AC coupled).
Power source specification
Power consumption
<980 W, single instrument, maximum
≤780 W, single unit (typical)
Source voltage and frequency 100 V to 240 V
RMS
, 50/60 Hz
115 V ±10%, 400 Hz
CAT II
Specifications
194 DPO70000SX Series User
