Accessory Tektronix part number
North America (Option A0) 161-0213-00
Universal Euro (Option A1) 161-0209-00
United Kingdom (Option A2) 161-0210-00
Australia (Option A3) 161-0211-01
Switzerland (Option A5) 161-0212-01
Japan (Option A6) 161-0213-00
China (Option A10) 161-0320-00
India (Option A11) 161-0325-00
Brazil (Option A12) 161-0358-00
No power cord (Option A99)
Operating requirements
WARNING.
To prevent injury and instrument damage, do not operate the instrument while the instrument is resting on its rear feet.
1. Place the instrument on a cart or bench. The instrument should rest on its bottom feet. An optional rack mounting kit is
available. Observe the following clearance requirements and dimensions:
■
Top: 0 in (0 mm)
■
Left side: 3 in (76 mm)
■
Right side: 3 in (76 mm)
■
Rear: 3 in (76 cm) beyond the rear feet to protect any cables connected to the rear panel
■
Bottom: 0 in (0 mm) standing on feet, flip stands down
CAUTION. To ensure proper cooling, keep the bottom and sides of the instrument clear of obstructions.
To ensure proper cooling, if the instruments are stacked on top of each other, the bottom feet must remain on the
instruments.
2. Width: 19.0 inches (483 mm)
3. Height: 6.0 inches (152 mm)
4. Before operating the instrument, verify the ambient temperature: 5 °C to +45 °C (+41 °F to +113 °F)
5. Verify the operating humidity: 8% to 80% relative humidity at up to +32 °C (+90 °F)
5% to 45% relative humidity above +32 °C (+90 °F) up to +45 °C (+113 °F), noncondensing, and is limited by a maximum
wet-bulb temperature of +29.4 °C (+85 °F) (derate relative humidity to 32% at +45 °C (+113 °F))
6. Verify the operating altitude: 3,000 m (9,843 feet), derate maximum operating temperature by 1 °C per 300 meters
(984.25 feet) above 1500 meters (4921.25 feet) altitude.
7. Maximum input voltage:
TekConnect channels: ≤1.2 V/FS settings:
±1.5 V relative to the termination bias (30 mA maximum).
Install your instrument
2 DPO70000SX Series User
