Tektronix MDO3024 User Manual

Installation
7. To use Ethernet, push Ethernet & LXI on
the lower menu.
Use the side me
nu buttons to adjust
your network settings, as needed. For
more information, see the e*Scope setup
information
below.
8. If you want to change socket server
parameters
, push Socket Server and enter
new values through the resulting side menu.
9. If you are u
sing GPIB , push GPIB. Enter the
GPIB address on the side menu, by turning
the M ultipurpo se a knob.
Talk/Listen
Address
(a) 1
This will set the GPIB address on an
attached TEK-USB-488 Adapter.
28 MDO3000 Series Oscilloscopes User Manual

Tektronix MDO3024 Specifications

General

Analog Channels	4
Bandwidth	200 MHz
Sample Rate	2.5 GS/s
Record Length	10 Mpoints
Digital Channels	16 (optional)
Spectrum Analyzer Frequency Range	9 kHz to 3 GHz
Digital Voltmeter	4-digit
Vertical Resolution	8 bits
Operating Temperature	0 °C to +50 °C
Display	9-inch WVGA (800x480) color display
Connectivity	USB, LAN, GPIB (optional)
Arbitrary Function Generator	50 MHz
Trigger Modes	Edge, Pulse Width, Logic, Video, Runt, Rise/Fall Time, Setup/Hold
Input Impedance	1 MΩ ±1%
Max Input Voltage	300 VRMS
Trigger Types	Edge, Pulse Width, Logic, Video, Runt, Rise/Fall Time, Setup/Hold
