Appendix H: List of Beta Commands and Features

Conditions:

Beta Command, s

ee conditions of use

. Default setting is INTERNal.

Group:

AFG

Syntax:

AFG:TRIGger:SOUrce {INTERNal|EXTernal}

AFG:TRIGger:SOUrce?

Arguments:

INTERNal - Trigger uses internal AFG source.

EXTernal - External trigger, connected to the scope main trigger signal.

Examples:

AFG:TRIGger:SOUrce INTERNal sets the trigger source to INTERNal.

H-10 MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual
