Commands Listed in Alphabetical Order
To set or query t
he amplitude or offset values, use the commands AFG:AMPLitude
and AFG:OFFSet.
NOTE. The AFG:OUTPut:LOAd:IMPEDance command must b e used before
using any of the amplitude/offset/highLevel/lowLevel/Preset commands, so that
saved setups are recalled with the proper load factor applied.
The following values can be set for high level:
AFG:HIGHLevel Setting Value
Load Impedance
FIFTY Ohm
Load Impedance
HIGHZ
Min Max Resolution Min Max Resolution
SINE
SQUare
PULSe
RAMP
NOISe
DC
1
HAVERSINe
CARDIac
ARBitrary
-1.245V 2.5V 1mV -2.49V 5.0V 2mV
SINC (Sin(x)/x)
-1.241V 2.5V 1mV -2.482V 5.0V 2mV
LORENtz
-1.239V 2.5V 1mV -2.478V 5.0V 2mV
GAUSsian
ERISe
EDECAy
-1.24V 2.5V 1mV -2.48V 5.0V 2mV
1
Whenthe:AFG:FUNCtionisspecified as DC, a change to the AFG:HIGHLevel value results in a corresponding change to :AFG:OFFset. A corresponding
change to :AFG:AMPLitude is remembered but is not applied until the :AFG:FUNCtion is changed to a function other than DC.
Conditions
MDO3000 series with option MDO3AFG installed and MDO4000C series with
option MDO4AFG installed only.
Group
AFG
Syntax
AFG:HIGHLevel <NR3>
AFG:HIGHLevel?
Arguments
Floating point number that represents the AFG high level value, in volts.
