Command Groups
Table 2-20: Configuration Commands (cont.)
Command
Description
CONFIGuration:BUSWAVEFORMS:LIN?
This query returns a boolean value to indicate whether the
optional LIN bus triggering and analysis feature is present.
CONFIGuration:BUSWAVEFORMS:MIL1553B?
This query returns a boolean value to indicate whether the
optional MIL-STD-1553 bus triggering and analysis feature is
present.
CONFIGuration:BUSWAVEFORMS:NUMBUS? This query returns the number of bus waveforms.
CONFIGuration:BUSWAVEFORMS:PA Rallel?
This query returns a boolean value to indicate whether the
parallel bus triggering and analysis feature is present.
CONFIGuration:BUSWAVEFORMS:RS232C?
This query returns a boolean value to indicate whether the
optional RS232 bus triggering and analysis feature is present.
CONFIGuration:BUSWAVEFORMS:SPI?
This query returns a boolean value to indicate whether the
optional SPI bus triggering and analysis feature is present.
CONFIGuration:BUSWAVEFORMS:USB? This query returns a boolean value to indicate whether the U SB
bus triggering and analysis feature is present.
CONFIGuration:BUSWAVEFORMS:USB:HS?
This query returns a boolean value to indicate whether the
high-speed US B bus triggering and analysis feature is present.
CONFIGuration:DIGITAl:MAGnivu?
This query returns a boolean value to indicate whether the
instrument supports the MagniVu feature for digital channels. If
there are no digital channels, the value returned is 0.
CONFIGuration:DIGITAl:MAXSAMPLERate? This query returns the maximum sample rate for digital channels,
in samples per second.
CONFIGuration:DIGITAl:NUMCHANnels? This query returns the number of digital channels.
CONFIGuration:DVM?
Indicates whether the Digital Voltmeter hardware is present. and
the DVM feature is enabled.
CONFIGuration:EXTVIDEO?
This query returns a boolean value to indicate whether the
optional extended video trigger features are present.
CONFIGuration:HISTOGRAM?
This query returns a boolean value to indicate whether the
waveform histogram feature is present.
CONFIGuration:NETWORKDRIVES?
This query returns a boolean value to indicate whether network
drives are present.
CONFIGuration:NUMMEAS? This query returns the number of periodic measurements.
CONFIGuration:REFS:NUMREFS? This query returns the number of reference waveforms.
CONFIGuration:RF:ADVTRIG?
This query returns a boolean value to indicate whether the
advanced RF trigger and analysis feature is present.
CONFIGuration:RF:BANDWidth? This query returns the maximum bandwidth, in hertz, for RF
channels. If there are no RF channels, the v alue returned is 0.
CONFIGuration:RF:MAXBANDWidth? Returns the maximum bandwidth, in hertz, for RF channels.
CONFIGuration:RF:NUMCHANnels? This query returns the number of RF channels present.
CONFIGuration:ROSC?
This query returns a boolean value to indicate whether the
instrument has an external reference oscillator (ROSC) input.
2-22 MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual
