Commands Listed in Alphabetical Order
Arguments
QString isaquo
ted string of up to 48 characters where the allowable characters
are 0, 1, and X. The bits specified in the quoted string replace the least significant
bits, leaving any unspecified upper bits unchanged.
Examples
SEARCH:SEARCH1:TRIGger:A:BUS:B1:ETHERn et:MAC:ADDRess:
SOUrce:VALue
”XXXXXXXXXX01010111111100000001111010101010101000” would set the
MAC destination address to search for to XX:35:FC:07:AA:C8 hex.
SEARCH:SEARCH1:TRIGger:A:BUS:B1:ETHERn et:MAC:ADDRess:
SOUrce:VALue?
might return
”XXXXXXXXXX01010111111100000001111010101010101000”.
SEARCH:SEARCH<x>:TRIG:A:BUS:B<x>:ETHER:MAC:ADDR:DEST:VAL
When the Ethernet search condition is set to MACADDress, this command specifies
the 48-bit MAC destination address value that is to be used in the search (along
with the source address value). The default is all X’s (don’t care).
SEARCH<x> is
the search number, which is always 1, and
B<x> is the bus number B1-B4.
NOTE. MAC Addresses are 48–bit values such as 08:00:11:1E:C9:AE hex. Use
the command BUS:B<x>:DISplay:FORMat to change the display format to hex.
Conditions
This command requires a DPO4ENET application module for DPO/MSO4000B
and MDO4000/B/C models.
Group
Search
Syntax
SEARCH
:SEARCH<x>:TRIG:A:BUS:B<x>:ETHER:MAC:A DDR:DEST:VAL
<QString>
SEARCH
:SEARCH<x>:TRIG:A:BUS:B<x>:ETHER:MAC:A DDR:DEST:VAL?
Related Commands
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:ETHERnet:CONDition
SEARCH:SEARCH<x>:TRIG:A:BUS:B<x>:ETHER:MAC:ADDR:SOU:VAL
Arguments
QString is a quoted string of up to 48 characters where the allowable characters
are 0, 1, and X. The bits specified in the quoted string replace the least significant
bits, leaving any unspecified upper bits unchanged.
2-640 MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual
