Commands Listed in Alphabetical Order
NOTE. For comma
nd sequence examples, see Appendix D. (See page D-1,
Waveform Transfer (WFMOutpre and CURVe Query) Examples.)
Example 1: Analog Waveform (channel 1 - 4)
Example 2: Digital Waveform (channel DO-D15)
Example 3: The Digital Collection with 4 Bytes Per Point with MagniVu Off
Example 4: The Digital Collection with 8 Bytes Per Point with MagniVu Off
Example 5: The Digital Collection with 4 Bytes Per Point with MagniVu O n
Example 6: The Digital Collection with 8 Bytes Per Point with MagniVu O n
Example 7: RF Frequency Domain Waveform
Group
Waveform Transfer
Syntax
WFMOutpre?
Examples
WFMOUTPRE? ? might return the waveform formatting data as:
:WFMOUTPRE:BYT_NR 2;BIT_NR 16;ENCDG ASCII;BN_FMT RI;BYT_OR
MSB;WFID “Ch1, DC coupling, 100.0mV/div, 4.000us/div, 10000
points, Sample mode ”;NR_PT 10000;PT_FMT Y;XUNIT “s”;XINCR
4.0000E-9;XZERO - 20.0000E-6;PT_OFF 0;YUNIT “V”;YMULT
15.6250E-6;YOFF :”6.4000E+3;YZERO 0.0000
WFMOutpre:BIT_Nr
This command specifies the number of bits per data point in the outgoing
waveform being transferred using the
CURVe? query. Changing the value of
WFMOutpre:BIT_Nr also changes the values of WFMOutpre:BYT_Nr and
DATa:WIDth. The waveform is specified by the DATa:SOUrce command.
(See page 2-95, Waveform Transfer Command Group.)
(See page D-1, Waveform Transfer (WFMOutpre and CURVe Query) Examples.)
NOTE. The
WFMOutpre:BYT _Nr
and
WFMOutpre:BIT _Nr
settings are
directly related; setting one causes the other to be set accordingly. For
example,
WFMOutp
re:BYT_Nr 2
causes
WFMOutpre_B IT_Nr
to be set to
16 (2 * 8 bits/byte). Similarly, setting
WFMOutpre: BIT_Nr
to 16 causes
WFMOutpre: BYT_Nr
to be set to 2.
Group
Waveform Transfer
2-960 MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual
