Removal and Installation Procedures

SPG600 & SPG300 Sync Pulse Generators Service Manual 6-9

Figure 6-3: SPG600 internal modules

A10 Main board

Fan

Power supply

A30 analog board (Option 02)

A40 SDI board (Option 03)
