Troubleshooting

SPG600 & SPG300 Sync Pulse Generators Service Manual 6-41

Figure 6-4: Troubleshooting procedure (4)

Are signals output

from 1+2/RIGHT and

3+4/LEFT correctly?

Replace the A10 Main board.

Yes

Are signals output

from AES 1+2 to

AES 7+8 correctly?

Replace the A10 Main board.

Yes

Are signals output

from SDI 3 to SDI 4

correctly?

Replace the A40 SDI board.

Yes

SPG600 Option 03 only

Done
