Removal and Installation Procedures

SPG600 & SPG300 Sync Pulse Generators Service Manual 6-19

c. Use a screwdriver with #2 Phillips tip to remove the two screws securing

the A40 SDI board to the bottom of the chassis.

d. Lift the board up and away from the chassis to complete the removal.

4. Reinstallation: Perform step 3 in reverse order to reinstall the A40 SDI board.

Figure 6-10: A40 SDI board removal

Spacer post

A40 SDI board

J610

A10 Main board

Bracket
