Setting Main Board Parameters after Replacement
SPG600 & SPG300 Sync Pulse Generators Service Manual 6-35
e. Press the up (
S) or down (T) arrow button to select WEB INTERFACE.
f. Press the left (
W) or right (X) arrow button to select Enable.
g. Press the ENTER button.
4. Start your Web browser on your PC and type the network address of the
instrument into the URL entry box.
5. In the Web browser window, click Launch SPG600/SPG300 Remote User
Interface. The Java applet windows appears.
6. Select Date and Time from the Utility pull-down menu to open the Date and
Time dialog box.
7. Set the year, month, day, and time.
8. Click the Apply button to enable the settings.
NOTE. Before you set the date and time of the instrument, be sure to check that
your PC’s system clock is set correctly.
