Getting Started
1-2 SPG600 & SPG300 Sync Pulse Generators User Manual
Initial Product Inspection
Perform the following product inspection procedure when you initially receive
your instrument:
1. Inspect the shipping carton for external damage, which indicates possible
damage to the instrument.
2. Remove the sync pulse generator from the shipping carton.
3. Check that the instrument has not been damaged in transit. The exterior should
not have any scratches or impact marks. Prior to shipment the instrument is
thoroughly inspected for mechanical defects.
4. Verify that the shipping carton contains the instrument, the standard
accessories, and any optional accessories that you ordered.
5. Perform the functional check procedure (refer to Functional Check Procedure
on page 1-5) after installing the instrument.
Contact your local Tektronix Field Office or representative if there is a problem
with your instrument or if your shipment is incomplete.
Table 1-1: Output capability between the SPG600 and the SPG300
SPG600 outputs
Signal Standard Option 02 Option 03 SPG300 outputs
Serial digital
Video 2 2 4 2
BNC audio 4 4 4 None
XLR audio 2 2 2 2*
Analog video 4 8 4 4
48 kHz word clock Yes Yes Yes Yes
* The SPG300 XLR outputs can be set to either serial digital or analog audio ports.
NOTE. Refer to Operating Basics beginning on page 2-1 for detailed information
about the rear-panel connectors.
NOTE. Save the shipping carton and packaging materials for instrument
repackaging in case shipment becomes necessary.
