Appendix A: Specifications
SPG600 & SPG300 Sync Pulse Generators User Manual A-3
Timing offset
Range Full color frame
Resolution < 1/27 MHz
Output signals
NTSC and NTSC No Setup Refer to Table 3-2 on page 3-7.
PAL Refer to Table 3-2 on page 3-7.
ID text Maximum 20 characters Blanking interval: 1 s, 2 s, 3 s, or off
Logo Gray scale, 4 level Blanking interval: 1 s, 2 s, 3 s, or off
Table A-2: Analog outputs (standard and Option 02) (cont.)
Characteristic Performance requirement Reference information
Table A-3: Serial digital interface (standard and Option 03)
Characteristic Performance requirement Reference information
Output connector type BNC
Number of outputs
Standard 2 SDI 1 and SDI 2
Option 03 (SPG600 only) 4 SDI 1, SDI 2, SDI 3, and SDI 4
Output impedance 75 Ω
Return loss > 15 dB
Formats 525-270, 625-270 (270 Mbps)
Signal amplitude, typical 800 mV ± 10%
Rise and fall time 0.4 ns to 1.5 ns 20% to 80%
Jitter, typical < 0.2 UI
Embedded audio The settings of the channels 9 to 16 are a
copy of those of the channels 1 to 8.
Number of channels 16 (4 groups)
Frequency Silence to 20 kHz 31 descrete settings
Level -60 dBFS to 0 dBSF 1 dB resolution
Preemphasis None, CD, and FCC
Click 1 s, 2 s, 3 s, 4 s, and Off
Timing offset
Range Full color frame
Resolution < 1/27 MHz
Output signals
525-270 Refer to Table 3-3 on page 3-10.
625-270 Refer to Table 3-3 on page 3-10.
ID text Maximum 20 characters Blanking interval: 1 s, 2 s, 3 s, or off
Logo Gray scale, 4 level Blanking interval: 1 s, 2 s, 3 s, or off
