3-10 SPG600 & SPG300 Sync Pulse Generators User Manual
After you select a signal set name (for example, COLOR BAR), use the left (
W) or
right (
X) arrow button to select a signal. You do not need to press the ENTER
button to enable the selection. Table 3-3 lists the available signals in each signal set.
Table 3-3: Selectable signals in each signal set (SDI)
Signal set name Selectable signals
525-270 format
COLOR BAR 100% Color Bars, 75% Color Bars, SMPTE Color Bars
FLAT FIELD 0% Flat Field, 20% Flat Field, 40% Flat Field, 50% Flat Field,
100% Flat Field, Field Square Wave
LINEARITY 5 Step, 10 Step, Modulated Ramp, Shallow Ramp, Valid Ramp,
Y Valid Ramp, B-Y Valid Ramp, R-Y Valid Ramp, Limit Ramp,
3 Channel Ramp
MONITOR Convergence, 75% Red Field, 75% Green Field, 75% Blue Field,
White Window, Gray Window, Gamut Test, 2 Pedestal & Pluge,
4 Pedestal & Pluge*
MULTIBURST 60% Multiburst, 60% Y Multiburst
SWEEP 100% Sweep, 60% Sweep
SDI Equalizer Test, PLL Test, Checkfield
TIMING Active Pic. Timing, 500 kHz Bowtie, 2.5 MHz Bowtie, Co-siting Pulse
PULSE BAR 2T Pulse & Bar, T Pulses, SinX/X, Multipulse
OTHER Chroma Freq. Resp., FCC Composite, FCC Multiburst,
NTC7 Composite, NTC7 Combination, Color Palette*
REC 801 100% Color Bars, 75% Color Bars, Black, Gray, White,
End-of-Line Pulses, Black-White Ramp, Yellow-Gray Ramp,
Gray-Blue Ramp, Cyan-Gray Ramp, Gray-Red Ramp,
Cb-Y-Cr-Y Ramp, White End-of-Line, Blue End-of-Line,
Red End-of-Line, Yellow End-of-LIne, Cyan End-of-Line
625-270 format
COLOR BAR 100% Colour Bars, 75% Colour Bars, 100% Bars Over Red,
75% Bars Over Red
FLAT FIELD 0% Flat Field, 40% Flat Field, 50% Flat Field, 100% Flat Field,
Field Square Wave
LINEARITY 5 Step, 10 Step, Modulated Ramp, Shallow Ramp, Y Valid Ramp,
B-Y Valid Ramp, R-Y Valid Ramp, Limit Ramp, 3 Channel Ramp
MONITOR Convergence, 75% Red Field, 75% Green Field, 75% Blue Field,
100% Red Field, White Window, Grey Window, Gamut Test,
2 Pedestal & Pluge, 4 Pedestal & Pluge*
MULTIBURST 60% Multiburst, 60% Y Multiburst
SWEEP 100% Sweep, 60% Sweep
SDI Equalizer Test, PLL Test, Checkfield
TIMING Active Pic. Timing, 500 kHz Bowtie, 2.5 MHz Bowtie, Co-siting Pulse
PULSE BAR 2T 10T Pulse & Bar, 2T 20T Pulse & Bar, SinX/X
OTHER CCIR 17, CCIR18, CCIR 330, CCIR 331, CCIR 331 G2
