3-8 SPG600 & SPG300 Sync Pulse Generators User Manual
PAL format
COLOR BAR 100% Colour Bars, 75% Colour Bars, 100% Bars Over Red,
75% Bars Over Red
FLAT FIELD 0% Flat Field, 40% Flat Field, 50% Flat Field, 100% Flat Field,
Black Burst, Field Square Wave
LINEARITY 5 Step, 10 Step, Modulated 5 Step, Modulated 10 Step, Ramp,
Modulated Ramp, Modulated Pedestal, Shallow Ramp
MONITOR Convergence, 75% Red Field, 100% Red Field, White Window,
Grey Window, 2 Pedestal & Pluge, 4 Pedestal & Pluge*, Safe Area*,
Monitor Setup*
MULTIBURST 100% Multiburst, 60% Multiburst
SWEEP 100% Sweep, 60% Sweep
PULSE BAR 2T Pulse & Bar, Sin X/X
OTHER CCIR 17, CCIR 18, CCIR 330, CCIR 331, UK ITS1, UK ITS 2,
UK 1 Line ITS, ITS Matrix 1*
* These signals are only available in SPG600 Option 02.
Table 3-2: Selectable signals in each signal set (analog) (cont.)
Signal set name Selectable signals
NOTE. The contents of each signal set are subject to change without notice due to
continuous improvements of the instrument.
