Menus
3-38 SPG600 & SPG300 Sync Pulse Generators User Manual
VIDEO STANDARD. Sets the video standard for the outputs. Use the left (
W) or right
(
X) arrow button to make the selection. You can select from the following options:
NTSC: NTSC for the analog outputs and 525-270 for the serial digital outputs.
NTSC No Setup: NTSC no setup for the analog outputs and 525-270 for the
serial digital outputs.
PAL: PAL for the analog outputs and 625-270 for the serial digital outputs.
Press the ENTER button to confirm the selection
ANALOG OUTPUT (STD). Sets the output configuration for the analog outputs (CH1
to CH4). Use the left (
W) or right (X) arrow button to make the selection. You can
select the following configurations:
BB:1,2,3 TEST: 4: Black burst signals are output from the CH1, CH2, and
CH3 connectors, and a test signal is output from the CH4 connector.
BB:1,2 TEST: 3,4: Black burst signals are output from the CH1, and CH2
connectors, and test signals are output from the CH3 and CH4 connectors.
BB:1 TEST: 2,3,4: A black burst signal is output from the CH1 connector,
and test signals are output from the CH2, CH3, and CH4 connectors.
BB: TEST: 1,2,3,4: Test signals are output from the CH1, CH2, CH3, and
CH4 connectors.
Press the ENTER button to confirm the selection.
ANALOG OUTPUT (OPT). Sets the output configuration for the optional analog
outputs (CH5 to CH8). Use the left (
W) or right (X) arrow button to make the
selection. You can select the following configuration:
BB:5,6,7 TEST: 8: Black burst signals are output from the CH5, CH6, and
CH7 connectors, and a test signal is output from the CH8 connector.
BB:5,6 TEST: 7,8: Black burst signals are output from the CH5, and CH6
connectors, and test signals are output from the CH7 and CH8 connectors.
BB:5 TEST: 6,7,8: A black burst signal is output from the CH5 connector,
and test signals are output from the CH6, CH7, and CH8 connectors.
BB: TEST: 5,6,7,8: Test signals are output from the CH5, CH6, CH7, and
CH8 connectors.
Press the ENTER button to confirm the selection.
