Command Descriptions
2- 104
TDS3000, TDS3000B, and TDS3000C Series Programmer Manual
HARDCopy:PALEtte
DISplay:FORMat
Sets or returns the display format. This command is equivalent to setting
XY Display in the DISPLAY menu.
Display
DISplay:FORMat { GATEDxyz | XY | YT | VECtorscope }
DISplay:FORMat?
GATEDxyz displays XY signals only when the Z (gating) channel is true. Gated
XYZ is similar to analog oscilloscope modulated XYZ mode except that the
displayed XY signal is either on or off; there is no intensity modulation. Gated
XYZ is useful for showing constellation diagrams.
XY displays the voltage of one waveform against the voltage of another. The
sources that make up an XY waveform are predefined and are listed in
Table 2--34. Displaying one source causes its corresponding source to be
displayed.
Table 2- 34: XY format pairs
X-Axis source Y-Axis source
Ch1 Ch2, Ch3, or Ch4
Ref1 Ref2, Ref3, or Ref4
YT sets the display to a voltage versus time format and is the default display
format.
VECtorscope sets the display to a vectorscope format. TDS3VID, TDS3SDI
only.
DISPLAY:FORMAT YT
selects a voltage versus time format for the display.
DISPLAY:FORMAT?
might return XY for the display format.
DISplay:XY:MODe
Related Commands
Group
Syntax
Arguments
Examples
Related Commands
