Tektronix TDS3000 Series Program Manual

Command Groups
TDS3000, TDS3000B, and TDS3000C Series Programmer Manual
2-27
Math Commands
Math commands provide access to math function definition. This table also
includes TDS3AAM Advanced Analysis application module remote command
syntax.
Table 2- 19: Math commands
Header Description
MATH? Returns definition for the math waveform
MATH:DEFINE Sets or returns the math waveform definition
for the active math operation (as set by
MATH:TYPe)
MATH:HORizontal:POSition<NR3> Sets the math horizontal display position
for FFT and dual waveform math with
reference sources only
MATH:HORizontal:SCAle<NR3> Sets the math horizontal di splay scale for FFT
and dual waveform math with reference
sources only
MATH:HORizontal:UNIts Sets or returns the math horizontal m easure-
ment units label
MATH:SPECTral:MAG Sets or returns the FFT waveform vertical
scale type (linear or dB)
MATH:SPECTral:WINdow Sets or returns the FFT window value
MATH:TYPe Sets or returns the math function (Dual, FFT,
DPO, or Advanced)
MATH:VAR<x>
(TDS3AAM)
Sets or returns the value of the user-defined
variableVAR1orVAR2
MATH:VERTical:POSition<NR3> Sets the math waveform display position
MATH:VERTical:SCAle<NR3> Sets the vertical display scale
MATH:VERTical:UNIts Sets or returns the math vertical m easurement
units label
MATH1:DEFINE
MATH1:HORizontal:POSition<NR3>
MATH1:HORizontal:SCAle
MATH1:HORizontal:UNIts
MATH1:SPECTral:MAG
MATH1:SPECTral:WINdow
MATH1:TYPe
MATH1:VAR<x>
MATH1:VERTical:POSition<NR3>
MATH1:VERTical:SCAle<NR3>
MATH1:VERTical:UNIts
Same as the equivalent MATH commands
