Tektronix TDS3000 Series Program Manual

Command Descriptions
2- 326
TDS3000, TDS3000B, and TDS3000C Series Programmer Manual
WFMPre—Additional Commands for Compatibility
Table 2--44 lists additional WFMPre commands. The oscilloscope ignores the set
form of these commands, and the query form generates event messages 100 and
420. The commands are included for compatibility purposes only.
Table 2- 44: Additional WFMPre commands
Command Argument Description
WFMPre:XMUlt
<NR3>
Horizontal (X-axis) scale factor
WFMPre:XOFf
<NR3>
Horizontal (X-axis) offset
WFMPre:ZMUlt
<NR3>
Z-axis scale factor
WFMPre:ZOFf
<NR3>
Z-axis position
WFMPre:ZUNit
<QString>
Z-axis units
WFMPre:ZZEro
<NR3>
Z-axis origin offset
WFMPre:<wfm>? (Query Only)
Returns the waveform formatting data for the waveform specified by <wfm>, if
that waveform is on or displayed. If that waveform is not on or displayed, the
query fails and the oscilloscope generates event message 420 (Query untermi-
nated) and 2244 (Waveform requested is not on).
NOTE. When querying WFMPRE:<wfm>:mnemonic information from the
oscilloscope, the value of <wfm> must be CH1, CH2, MATH, MATH1, REF1,
REF2, REF3 or REF4 for 2 channel models; <wfm> may be CH3 or CH4 in
addition to the previous set for 4 channel models.
When sending WFMPRE:<wfm>:mnemonic information to the oscilloscope, the
value of <wfm> must be REF1, REF2, REF3 or REF4. The oscilloscope ignores
<wfm> for any value other than REF1 through REF4.
The WFMPre:<wfm>:mnemonic commands do not use the values set by the
DATA:SOUrce or DATA:DESTINATION commands
Waveform
WFMPre:<wfm>?
Group
Syntax
