Tektronix TDS3000 Series Program Manual

Command Descriptions
2- 204
TDS3000, TDS3000B, and TDS3000C Series Programmer Manual
Math
MATH:VERTical:POSition <NR3>
MATH:VERTical:POSition?
<NR3> is the math vertical position in divisions from center screen.
MATH:VERTICAL:POSITION?
might return :MATH:VERTICAL:POSITION -3.0E0 indicating the the math
waveform is 3 division below center screen.
MATH:VERTical:SCAle
Sets the vertical display scale. This command is equivalent to changing the
Vertical SCALE knob that controls the waveform zoom factors. The math
waveform scale is not affected by this control. The math calculation software
automatically determines the optimum vertical scale through examination of
input waveform data.
NOTE. The vertical display scale is reset to the waveform preamble scale, when a
vertical scale change to a math source waveform results in a new math autoscale
operation. The vertical display scale should be changed only after math source
waveform adjustments are complete.
Math
MATH:VERTical:SCAle <NR3>
MATH:VERTical:SCAle?
<NR3> is the math vertical scale in math waveform vertical units.
MATH:VERTICAL:SCALE 5.0e0
sets the math vertical scale to 5 math waveform units per division.
Group
Syntax
Arguments
Examples
Group
Syntax
Arguments
Examples
