Command Groups
TDS3000, TDS3000B, and TDS3000C Series Programmer Manual
2-23
Table 2- 16: Mask commands (cont.)
Header Description
MASK:LOCk Sets or returns the mask lock to waveform
mode
MASK:MARGIN:HORizontal Sets or returns the User mask’s horizontal
margin percentage
MASK:MARGIN:VERTical Sets or returns the User mask’s vertical margin
percentage
MASK:MASK<m> DELEte Deletes the specified mask segment from the
User mask, whether or not the User mask is
the current mask
MASK:MASK<m>:COUNt? Returns the number of hits on the specified
mask segment in the current mask
MASK:MASK<m>:NR_Pt? Returns the number of points that make up the
specified mask segment of the currently-dis-
played mask
MASK:MASK<m>:POINTS Sets or returns the X-Y user coordinates of all
points in the specified mask segment
MASK:MASK<m>:POINTSNorm Sets or returns the normalized coordinate
points of the specified mask segment
MASK:MASK<m>:POINTSPcnt Sets or returns the points in the specified
mask segment, in percentage coordinates
MASK:MASKPRE:AMPlitude Sets or returns the current mask’s nominal
pulse amplitude in volt s
MASK:MASKPRE:HSCAle Sets or returns the nominal timing resolution
used to draw the mask, in time/division
MASK:MASKPRE:HTRIGPOS Sets or returns the nominal trigger position
(pulse leading edge) used to draw the mask as
a fraction of the display width
MASK:MASKPRE:PATTERNBITS
Sets or returns the number of bi ts used for
serial trigger for the current standard
MASK:MASKPRE:PRESAMPBITS
Sets or returns the number of bi ts before the
(isolated one) pulse leading edge in serial
trigger
MASK:MASKPRE:RECOrdlength
Sets or returns the nominal record length for
pulse mask testing
MASK:MASKPRE:SERIALTRIG Sets or returns enabling of serial trigger for the
current mask standard
MASK:MASKPRE:TRIGTOSAMP Sets or returns the time, in seconds, from the
(leading edge) trigger position to the pulse bit
sampling position
