Tektronix TDS3000 Series Program Manual

Command Groups
TDS3000, TDS3000B, and TDS3000C Series Programmer Manual
2-25
Table 2- 16: Mask commands (cont.)
Header Description
MASK:USER:MASK<m>:POINTS Sets or returns the X-Y user coordinates of all
points in the specified User mask segment
MASK:USER:MASK<m>:POINTSNorm Sets or returns the normalized coordinate
points of the specified User mask s egment
MASK:USER:MASK<m>:POINTSPcnt Sets or returns the points in the specified User
mask segment, in percentage coordinates
MASK:USER:MASKPRE:AMPlitude Sets or returns the User mask’s nominal pulse
amplitude in volts
MASK:USER:MASKPRE:HSCAle Sets or returns the nominal timing resolution
used to draw the User mask, in time/division
MASK:USER:MASKPRE:HTRIGPOS Sets or returns the nominal trigger position
(pulse leading edge), as a f ract ion of the
display width, used to draw the User mask
MASK:USER:MASKPRE:PATTERNBITS Sets or returns the number of bits used for
serial trigger for the User mask standard
MASK:USER:MASKPRE:PRESAMPBITS Sets or returns the number of bits before the
(isolated one) pulse leading edge in User
mask
MASK:USER:MASKPRE:RECOrdlength Sets or returns the nominal record length for
User mask
MASK:USER:MASKPRE:SERIALTRIG Sets or returns enabling of serial trigger for the
User mask standard
MASK:USER:MASKPRE:TRIGTOSAMP Sets or returns the time, in seconds, from the
(leading edge) trigger position to the pulse bit
sampling position, for the User Mask
MASK:USER:MASKPRE:VOFFSet Sets or returns the nominal vertical offset, in
volts, used to vertically offset the input
channels
MASK:USER:MASKPRE:VPOS Sets or returns the nominal vertical position, in
divisions, used to vertically position the input
channels
MASK:USER:MASKPRE:VSCAle Sets or returns the nominal vertical scale, i n
volts per division, used to vertically scale the
input channels
MASK:USER:MASKPRE:WIDTH Sets or returns the User mask standard’s
nominal bit width in seconds
TRIGger:A:COMMunication:STANdard Sets or returns the current standard A trigger
communication trigger settings
TRIGger:MAIn:COMMunication:STAN-
dard
Sets or returns the current standard main
trigger communication trigger settings
