Save/Recall
TDS3000 Series User Manual
3–45
Editing File, Directory, Reference Waveform, or Instrument Setup Names.
You can edit file names,directory names, reference waveform and
instrument setup labels, and Ethernet parameters (TDS3EM only).
Use the general purpose knob to select an alphanumeric character.
Use the screen buttons described below to edit and enter the new
name.
Screen button Function
Enter Char Enters the selected character into the field.
² and ³ Moves the cursor to a different character in the field.
Back Space Deletes the character before the cursor location.
Delete Deletes the character at the cursor location.
Clear Erases the current field value.
° and ± Selects the field that you want to edit.
OK Accept Applies all field values.
MENU OFF Exits the menu without applying field values.
