Specifications (Cont.)
Horizontal
Acquisition (horizontal)
resolution
Normal Fast trigger
Record length 10,000 points 500 points
Acquisition rate,
maximum
Up to 450 waveforms/s Up to 3,000 waveforms/s
S
a
m
p
le
r
a
te
r
ang
e
Acquisition
resolution
TDS3012
TDS3014
TDS3032
TDS3034
TDS3052
TDS3054
Normal 100 S/s to
1 GS/s
100 S/s to
2.5 GS/s
100 S/s to
5 GS/s
Fast trigger 5 S/s to
1.25 GS/s
5 S/s to
2.5 GS/s
5 S/s to
5 GS/s
Seconds/division
range
— 4 ns/div to
10 s/div
2 ns/div to
10 s/div
1 ns/div to
10 s/div
 Sample rate and
delay time accuracy
±200 ppm over any ≥1 ms time interval
Trigger
External trigger input,
typical
1 MW in parallel with 17 pF, TekProbe compatible
(TDS3012, TDS3032, TDS3052 only)
Ex
ter
na
l
tri
gg
er
m im m volt e
Overvoltage category Maximum voltage
m
ax
im
u
m
volt
ag
e
CAT I Environment (refer to
page A–12)
150 V
RMS
(400 V
pk
)
CAT II Environment (refer to
page A–12)
100 V
RMS
(400 V
pk
)
For steady-state sinusoidal waveforms, derate at 20 dB/decade
above 200 kHz to 13 V
pk
at 3 MHz and above.
External trigger maxi-
mum floating voltage
0 V from chassis (BNC) ground to earth ground, or
30 V
RMS
(42 V
pk
) only under these conditions: no signal voltages
>30 V
RMS
(>42 V
pk
), all common leads connected to the same
voltage, no grounded peripherals attached
