Tektronix TDS3000 Series User Manual

Appendix A: Specifications
A–4
TDS3000 Series User Manual
Specifications (Cont.)
Vertical
Pe
ak d
etect
or
Envelope pulse re-
oeticl
Minimum width of pulse with amplitude of ≥2 div to capture 50%
or greater amplitude
sp
o
ns
e
,
t
yp
ic
a
l
Sample rates ≤125 MS/s Sample rates ≥250 MS/s
1 ns 1/sample rate
DC gain accuracy ± 2%, derated at 0.07%/°C for temperatures below +18° C and
above +28° C, in Sample or Average acquisition mode
DC measurement ac-
curacy
Measurement type DC Accuracy (in volts)
Sample acquisition
mode, typical
Absolute measurement of any
waveform point, and High,
Low, Max, and Min measure-
ments.
± [0.02
1
 | reading – (offset
– position) | + offset accuracy +
0.15 div + 0.6 mV]
Delta voltage between any two
points on a waveform, and all
other automatic measure-
ments.
± [0.02
1
 | reading | +
0.15 div + 1.2 mV]

Aver
ag
e
acquisition mode
(≥16 averages)
Absolute measurement of any
waveform point, and High,
Low, Max, and Min measure-
ments.
± [0.02
1
 | reading – (offset –
position) | + offset accuracy
+ 0.1 div]
Delta voltage between two
points on a waveform, and all
other automatic measure-
ments.
± [0.02
1
 | reading | +
0.05 div]
O
ffs
et
r
ang
e
Scale range Offset range
1 mV/div to 9.95 mV/div ±100 mV
10 mV/div to 99.5 mV/div ±1 V
100 mV/div to 995 mV/div ±10 V
1 V/div to 10 V/div ±100 V
Offset accuracy
± (0.005  | offset – position | + 0.1 div)
1 0.02 term (gain component) derated at 0.00025/°C above 30° C
