Tektronix TDS3000 Series User Manual

Appendix B: Factory Setup
B–2
TDS3000 Series User Manual
Control Changed by factory setup to
Display graticule type Full
Display backlight High
Display color palette Normal
Dual waveform math function Ch 1 + Ch 2
Edge trigger coupling DC
Edge trigger level 0.0 V
Edge trigger slope Rising
Edge trigger source Channel 1
Horizontal delay On
Horizontal delay time 0 ns
Horizontal trigger position 10%
Horizontal time/div
400 ms/div
Horizontal zoom Off
Horizontal zoom position 50%
Horizontal zoom time/div
400 ms/div
Measure gating Off (Full Record)
Measure high-low setup Auto
Measure high reference 90% and 0 V
Measure low reference 10% and 0 V
Measure mid reference 50% and 0 V
