Appendix B: Factory Setup
TDS3000 Series User Manual
B–3
Control Changed by factory setup to
Overwrite lock No change
Reference waveforms No change
Saved setups No change
Trigger holdoff 250.8 ns
Trigger mode Auto
Trigger type Edge
Utility language No change
Utility date/time display On
Utility I/O No change
Utility hard copy No change
Vertical bandwidth Full
Vertical coupling
DC 1 MW
Vertical invert Off
Vertical offset 0 V
Vertical position 0 div
Vertical probe setup Voltage, 1 X (unless non-1 X probe
attached)
Vertical volts/div 100 mV/div
Video trigger standard 525/NTSC
Video trigger on All lines
Waveform file format No change
XY display Off
