Appendix E: Performance Verification
TDS3000 Series User Manual
E–9
Vertical
SCALE
setting
Invert
setting
Band-
width limit
setting
Offset
Input
voltage
Low
limit
High
limit
1 mV/div Off 20 MHz 96.5 mV 100 mV 99.25 mV 100.8 mV
2 mV/div Off 20 MHz 0.0 V –7 mV –7.540 mV –6.460 mV
5 mV/div Off 20 MHz –82.5 mV –100 mV –101.8 mV –98.24 mV
50 mV/div Off Full 825 mV 1.0 V 982.4 mV 1.018 V
50 mV/div Off Full 825 mV 650 mV 632.4 mV 667.6 mV
50 mV
delta
1
340.5 mV 359.5 mV
90 mV/div
2
Off Full 0.0 V –315 mV –339.3 mV –290.7 mV
200 mV/div Off 150 MHz
3
9.3 V 10 V 9.900 V 10.10 V
1 V/div On
4
150 MHz
3
–6.5 V 10 V –10.30 V –9.698 V
1
Refer to step 15e on page E–8 to calculate 50 mV delta measurement.
2
Push the Vertical MENU button, push the Fine Scale screen button, then
use the general purpose knob to adjust setting to 90 mV/div.
3
Use the Full bandwidth setting on the TDS3012 or TDS3014 oscilloscopes.
4
Make sure to turn Invert setting to On for this measurement.
