Specifications
TDS5000B Series Specifications and Performance Verification
1-9
Table 1- 2: Channel input and vertical specifications (Cont.)
Characteri sti c Description
TDS5032B, TDS5034B, TDS5052B,
TDS5054B, TDS5054BE
SCALE range Offs et range
1MΩ coupling 1 mV/div to 99.5 mV/ div ±1V
100 mV/div to 1 V/div ±10 V
1.01 V/div to 10 V/div ±100 V
50 Ω coupling 1 mV/div to 99.5 mV/ div ±1V
100 mV/div to 1 V/div ±10 V
TDS5104B SCALE range Offs et range
1MΩ coupling 1 mV/div to 99.5 mV/ div ±1V
100 mV/div to 1 V/div ±10 V
1.01 V/div to 10 V/div ±100 V
50 Ω coupling 1 mV/div to 50 mV/div ±0.5 V
50.5 mV/div to 99.5 m V/div ±0.25 V
100 mV/div to 500 mV/div ±5V
505 mV/div to 1 V/div ±2.5 V
