Tektronix THDP0100 User Manual

Accessories
Table 1: Voltage derating for THDP0100 probe standard accessories
Combined probe
and accessory common-mode voltage and input
voltage-to-earth ratings
Accessory (Tektronix part number) THDP0100 THDP0200
1
TMDP0200
1
Extender lea
ds
(196-3523-xx)
2300 V CAT I
1000 V C AT III
1000 V CAT II
600 V CAT III
550VCATI
300 V CAT III
Test probe (TATP)
(part of 020
-3070-xx kit)
1000 V CAT I
1000 V CAT II
1000 V CAT II
600 V CAT II
550VCATI
300 V CAT II
Small hook
tip (TASH)
(part of 020-3070-xx kit)
2300 V CAT I
1000 V CAT II
1000 V CAT I
I
600 V CAT II
550VCATI
300 V CAT II
Large hook tip (TALH)
(part of 020-3070-xx kit)
2300 V CAT I
1000 V CAT II
1000 V CAT II
600 V CAT II
550VCATI
300 V CAT II
1
The THDP0200 & TMDP0200 standard accessories can be used with the THDP0100 probe at the reduced voltage levels listed in this table.
Table 2: Voltage derating for THDP0200 & TMDP0200 probe standard accessories
Combined probe and accessory common-mode voltage
and input voltage-to-earth ratings
12
Accessory (Tektronix part num ber) THDP0100
3
THDP0200 TMDP0200
Extender leads
(196-3523-xx)
2300 V CAT I
1000 V CAT III
1000 V CAT II
600 V CAT III
550VCATI
300 V CAT III
Handheld probes
4
(TP175-FL)
1000 V CAT I
1000 V CAT III
1000 V CAT II
600 V CAT III
550VCATI
300 V CAT III
Pogo pin tip adapters and tips
(020-3107-xx)
150 V CAT II 150 V CAT II 150 V CAT II
Extended test probe adapters
(012-1724-xx)
300VCATI
300 V CAT II
300 V CAT II 300 V CAT I
300 V CAT II
Hook clips
(AC280-FL)
1000 V CAT I
1000 V CAT III
1000 V CAT II
600 V CAT III
550VCATI
300 V CAT III
Pincer clips
(AC283-FL)
1000 V CAT I
1000 V CAT III
1000 V CAT II
600 V CAT III
550VCATI
300 V CAT III
Alligator clips
(AC285-FL)
1000 V CAT I
1000 V CAT III
1000 V CAT II
600 V CAT III
550VCATI
300 V CAT II
Crocodile clips
(344-0670-xx)
300 V CAT I 300 V CAT I 300 V CAT I
1
The operating altitude of the probe is derated to 2000 m (6560 ft) when used with these accessories.
2
The voltage rating and CAT rating are de-rated to the voltage in this table when used with these accessories.
3
TheTHDP0100probecanbeusedwiththeseaccessoriesatthereducedvoltagelevelslistedinthistable.
4
When using the TP175-FL test probes in CAT III circuits, the tip must be in the retracted position to prevent risk of arc flash. The exposed metal tip
i
s about 3.7 mm (0.15 in) in the retracted position.
9 THDP0100/0200 & TMDP0200 High Voltage Differential Probes Instruction Manual
