Tektronix TLA5204 User Manual

Operating Information
2-2
TLA5000 Series Service Manual
Rear panel
AC Power
Ground connection
Figure 2- 1: Location of the ground connection
The accessory connections are the same as those on a personal computer. The
connection points are shown in Figure 2 --2 on page 2--3.
WARNING. Before installing accessories to connectors (mouse, keyboard, etc.),
power off the logic analyzer. See Powering Off the Logic Analyzer on
page 2--5.
Connect the Accessories

Tektronix TLA5204 Specifications

General

Brand	Tektronix
Model	TLA5204
Category	Measuring Instruments
Language	English
