Performance Verification
TLA5000 Series Service Manual
4-19
The software will begin the procedures and display a list of results in the
window.
8. After the first set of procedures are done, click the Next button to display the
instructions for the next step. Move the probes on the test fixture as indicated
by the instructions.
9. After changing the connections, click the Next button to continue the
procedures.
10. Repeat steps 7 through 8 as indicated by the software.
11. After the procedure finishes, click the Next button to open the Finish dialog
box where you can save the results to a file. Enter a file name and click the
Save button. You can use the Save dialog to save the file to a folder of your
choice or use the default location.
12. Click the Finish button to complete the process.
Logic Analyzer Certification
This section describes the procedures to certify the logic analyzer. You can
certify the logic analyzer without completing the main performance verification
procedures. Table 4--4 lists the certifiable parameters for the logic analyzer.
Table 4- 4: Logic analyzer certification test
Performance verification test name Specification tested
1. Thresholds
1
Threshold accuracy
1
Certifiable parameter
To certify the logic analyzer, use the performance verification software and click
the Certification button. Perform the required procedure and then print the results
to obtain a copy of the software-generated calibration data report.
NOTE. The certification procedures have the same prerequisites as the perfor-
mance verification procedures. Refer to Prerequisites on page 4--9 for a
detailed list of prerequisites.
These procedures require the same setups as described for the Performance
Verification procedures. It is assumed that the logic analyzer is already connected
to the test fixture and that the performance verification software is installed on
the logic analyzer.
Equipment Setups
