Performance Verification
TLA5000 Series Service Manual
4-3
Test Equipment
The procedures use external, traceable signal sources to directly test characteris-
tics that are designated as checked (n) under the TLA5000 Series Logic
Analyzer specifications. These specifications are listed in the Tektronix Logic
Analyzer Product Specifications document on the Tektronix Logic Analyzer
Family Product Documentation CD or can be downloaded from the Tektronix
website as a PDF file.
Table 4--1 shows the required equipment list; this equipment is required for the
performance verification and adjustment procedures.
Table 4- 1: Test equipment
Item number and description Minimum requirements Example
1. TLA5000 Logic Analyzer TLA5000 Seri es Logic Analyzer with TLA
Application software V4.3 or higher
TLA5204 Logic Analyzer
2. Logic analyzer probes P6417, P6418, or P6419 logic analyzer
probes. One probe required for every
17-channels
1
No substitute allowed
3. Performance Verification test
fixture wit h accessories
TLACAL1 test fixture No substitute allowed
4. Digit al Multimeter with probes Agilent 34401A, 6.5 digit display, 35 ppm, 1
year accuracy, 1000 readings per minute,
100 nV sensitivity, GPIB controllable
No substitute allowed
5. USB-GPIB controller: National I nstruments 778195-01
Windows 2000 compatible wit h 2 m cable
Tekt ronix iView cable
6. RS-232 cable 2 m RS-232 cable, 9-pin female-to-female
connector
Tekt roni x part number 012-1379-00
1
The P6419 logic analyzer probes can be used to complete al l of the verification procedures. The P6417 and the P6418
logic analyzer probes can be use to complete all of the verification procedures except the Setup and Hold procedures.
Test Equipment Setup
The TLACAL1 Performance Verification and Adjustment test fixture and the
performance verification software are required to perform the performance
verification procedures, certification procedures, and adjustment procedures.
