Performance Verification
TLA5000 Series Service Manual
4-21
probes from the logic analyzer to the test fixture. If necessary, refer to the
test fixture label to determine the correct probe connection.
NOTE. When connecting the P6419 Logic Analyzer probes, make sure that the
alignment pin on the probe head aligns with the hole on the test fixture. Tighten
the probe head screws by alternating between them until they are finger tight (no
more than 1 in-lbs of torque).
6. Click the Next button to begin the certification procedure.
The software will begin the procedures and display a list of results in the
window.
7. After the first set of procedures are done, click the Next button to display the
instructions for the next step. In most cases you only need to move a probe
or connect a different probe to the test fixture.
8. After changing the connections, click the Next button to continue the tests.
9. Repeat steps 7 through 8 as indicated by the software.
10. After the procedure finishes, click the Next button to open the Finish dialog
box where you can save the results to a file. Enter a file name and click the
Save button. You can use the Save dialog to save the file to a folder of your
choice or use the default location.
11. Click the Finish button to complete the process.
12. Locate the file that you saved in step 10 and print the file for your records.
13. Power down the test fixture and then disconnect the remaining test equip-
ment.
This completes the certification procedures.
