Preface
Option
Instrument Description
EYE WFM7120
Adds support f
or Eye pattern display, jitter measurements, and
cable parameter measurements.
PHY WFM7120
Adds option EYE capabilities, plus s upport for jitter waveform
and automated eye measurements.
DAT WFM6120
WFM7120
Adds data analysis and ANC Data Inspector capabilities.
Allows for l
ogic-level view of video and embedded audio data
stream and ANC data extraction.
Waveform Monitors Quick Start User Manual xiii
