Getting Acquain
tedWithYourInstrument
Pix Mon Connector Pin Assignment
This is the video picture output. The output is compatible with standard analog PC monitors, either CRT or LCD-based. The
PIX MO N connector is a 15-pin D -type connector with socket contacts.
Pin Pin name
1 Red Video
2
Green Video
3 Blue Video
4 Not connected
5
Ground
6
Red Ground
7
Green Ground
8
Blue Ground
9
Not C onnected
10
Not C onnected
11
Not C onnected
12
Not C onnected
13
Horizontal S ync
14
Vertical Sync
15
Not C onnected
Waveform Monitors Quick Start User Manual 17
