TELEVAC CC-10 - S (status) command

CC-10
INSTRUMENT MANUAL
Phone:(215) 947-2500 fax:(215) 947-7464 e-mail:sales@televac.com web site:www.televac.com
CC-10 MANUAL REV D
Page 28 of 40
Y
TELEVA
Command
Mode
Explanation
Response
Date
Explanation
5
Set analog output
parameters
1ABB
1: select log output mode
A: voltage span for 1 decade
0: 0.5V/decade,
1: 1.0V/decade BB: full scale
voltage when A=0, BB must be
07 to 10
When A=1, BB must be 00
to 03 for Torr and mbar unit, or
must be 02 to 05 for Pa unit
2000
Select combined output mode
3000
Select special mode for remote
display unit
1. host to gauge
1 2 3 4 5
< STX>
Address
(HEX)
C
mode
< CR>
2. gauge to host
1 2 3 4 5 6 7 8
< STX>
Address
(HEX)
C
response data
< CR>
3. Command & response
command
mode
Explanation
Response
data
Explanation
C
1
Trigger crystal gauge
atmospheric pressure
adjustment
0000
OK
0001
ErrA
2
Trigger crystal gauge zero
adjustment
0000
OK
0001
ErrV
C (control) command
